Case study
Raiden Technologies integrated access control, intruder detection, 8MP CCTV, IP video intercoms and a PA extension at Hebersham Public School’s new 40-place preschool, linking them to the school’s existing security system.
Raiden Technologies delivers integrated school security in Sydney, connecting preschool access control, alarms, CCTV, intercoms and PA to existing school systems.
Raiden supplied and installed a complete electronic security package for the new 40-place preschool at Hebersham Public School in Western Sydney, built to the NDY engineering specification. The new Integriti system connects to the school’s existing Concept 4000 platform through underground cabling, so staff manage both sites from one system.
The new preschool needed child-safe access control, alarm monitoring, CCTV and communications that met the Department’s specification from day one. It also had to work seamlessly with the main school’s existing security and PA systems. Keeping young children secure while letting families and staff move easily through the site required tightly controlled entry points and clear visitor screening.
Raiden installed a new Inner Range Integriti system with ILAM door controllers, SIFER card readers, a keypad, and full intruder detection including a duress button. Everything connects to the school’s Concept 4000 system. Raiden added 8MP vandal-resistant CCTV with 60-day recording, an Aiphone IX IP video intercom at the entry points, and an extension of the school’s Australian Monitor PA so announcements reach the preschool.
Security and electrical systems delivered on this project.
Inner Range Integriti with ILAM door controllers, SIFER multi-format card readers and a keypad, licensed for all doors.
PIR motion detectors, reed switches and 32-zone expanders, all monitored through the school’s Concept 4000 system.
Duress button in the accessible bathroom, linked to the security system.
8MP vandal-resistant dome cameras on an 8-channel Hikvision NVR with 12TB storage and a pole-mounted 32" monitor.
Aiphone IX video door stations and monitors to screen visitors before they’re let in.
School Australian Monitor PA extended over IP via Barix Exstreamer, with 4 Bosch ceiling speakers and a 250W amplifier.
The preschool opened with a fully integrated security and communications system that staff manage alongside the main school. Families and staff enter by card or through the video intercom, and the whole site is covered by high-resolution CCTV with 60 days of footage kept.
Testimonial
““Raiden made the security side of our new preschool straightforward. Everything links back to the main school, so we manage it all from one place. The team was professional and tidy, and they worked around the rest of the build without any fuss.””
Explore connected security, electrical and industry capability across Sydney and NSW.
Security Maintenance
Planned, preventative and reactive commercial security maintenance for CCTV, access control, alarms and integrated security systems, with 24/7 support across Sydney and NSW.
Read moreAccess Control
Commercial access control for offices, retail, healthcare and hospitality across Sydney. Card, biometric and remote-managed.
Read moreAlarm Systems
Commercial alarm and intruder detection systems across Sydney and NSW, video-verified and backed by Raiden’s maintenance plans.
Read moreCCTV
Commercial CCTV design and installation across Sydney and NSW. Hikvision & Hanwha hardware, AI analytics, expert placement.
Read more
Commercial Real Estate
Multi-tenant access control, CCTV and boom gates for office buildings and strata across Sydney. Remote management, local support.
Government Security
CM3-accredited security and electrical integrator for government & council facilities across NSW. Compliant, accountable, local.
Healthcare Security
Slip and fall detection, access control and CCTV for hospitals & aged care across NSW. Licensed electrical infrastructure included.
Retail Security
CCTV, access control and loss prevention AI for retail across Sydney & NSW. Licensed electricians on staff. Get a site assessment.
Usually access control, intruder detection, CCTV, a visitor intercom and a PA connection to the main school. At Hebersham, Raiden delivered all five as one package to the project’s engineering specification.
Yes. Raiden installed a new Integriti system at the Hebersham preschool and connected it to the school’s existing Concept 4000 platform through underground cabling, so both sites run as one system.
It’s set by each project’s specification. The Hebersham preschool required 60 days, which Raiden achieved with a 12TB recorder and 8MP cameras.
Integriti is Inner Range’s commercial access control and alarm platform, widely used in schools and government buildings. It manages card access, alarm zones and door scheduling from a single system, and it works with older Concept 4000 sites.
Yes. Raiden extended Hebersham’s existing Australian Monitor PA to the preschool using Barix IP audio devices, new ceiling speakers and an amplifier, so school-wide announcements also play in the preschool.
